ZAMBELIS DESIGN LED Strip 10W/m IP65 1m for 48V Rail: continuous lighting for magnetic track

The ZAMBELIS DESIGN LED strip of 1 m is specifically designed to integrate into the 48V magnetic tracks of the ZAMBELIS range, providing a continuous, diffuse and uniform light line over 1,000 mm. With a power of 10 W/m and a flux of 700 lm/m in warm white light 3200K, it delivers premium color rendering with a CRI above 90.

Its silicone casing provides IP65 protection against water splashes, making it suitable for damp areas or covered outdoor spaces. It is DALI dimmable for precise ambiance management, and compatible with ZAMBELIS DESIGN 48V magnetic tracks (2082, 2083, 2084, 2085).

Key features:

  • Designed for ZAMBELIS DESIGN 48V magnetic tracks, length 1 m
  • CRI> 90, 3200K, 700 lm/m, IP65 silicone
  • DALI dimmable for fine-tuned ambiance management
  • 3-year warranty
Ref: ZAM.E386

LED Strip 10W/m Dimmable IP65 1m for 48V Rail ZAMBELIS DESIGN E386

save_alt Download the technical sheet

Color

Warm white - 3200K

Diffuser

Driver

Product color

Currently out of stock
Delivery: contact us
Pricing is only available to customers who are logged into their account and whose access request has been validated.
To request access, go here

ZAMBELIS DESIGN LED Strip 10W/m IP65 1m for 48V Rail: continuous lighting for magnetic track

The ZAMBELIS DESIGN LED strip of 1 m is specifically designed to integrate into the 48V magnetic tracks of the ZAMBELIS range, providing a continuous, diffuse and uniform light line over 1,000 mm. With a power of 10 W/m and a flux of 700 lm/m in warm white light 3200K, it delivers premium color rendering with a CRI above 90.

Its silicone casing provides IP65 protection against water splashes, making it suitable for damp areas or covered outdoor spaces. It is DALI dimmable for precise ambiance management, and compatible with ZAMBELIS DESIGN 48V magnetic tracks (2082, 2083, 2084, 2085).

Key features:

  • Designed for ZAMBELIS DESIGN 48V magnetic tracks, length 1 m
  • CRI> 90, 3200K, 700 lm/m, IP65 silicone
  • DALI dimmable for fine-tuned ambiance management
  • 3-year warranty

General characteristics
Lifetime 30,000 h
Brand ZAMBELIS
Range DESIGN
Product family LED strips
Warranty 3 years
Electrical characteristics
Voltage 24-48 V DC
Power 10 W/m
Electrical class Class III
EU energy class 2019/2015 E
Lighting characteristics
Technology LED
Lumens output 700 lm/m
Lifetime LXBY L70B50
Diffuser Opale
Beam Angle 100 deg
IRC > 90
Physical characteristics and dimensions
Length 1 000 mm
Net weight 0.4 kg
Waterproof YES
IP IP65
Product color White
Working temperature -35 °C to 50 °C
Detailed color White
Standards and regulations
Carbon footprint 36 kgCO2eq
