In-Ground Recessed Fixture ZAMBELIS DESIGN Stainless Steel 24V: 10x60° beam for a linear grazing effect on outdoor surfaces

The in-ground recessed fixture ZAMBELIS DESIGN Stainless Steel E509 in stainless steel stands out with its specific 10° × 60° beam, a linear asymmetric profile that grazes floors, retaining walls or surfaces with a dramatic and sophisticated grazing effect. Powered at 24 V DC, it delivers 3 W for 218 lm in very warm light at 2,700 K, with a honeycomb diffuser to contain the light with precision.

Its diameter of Ø 65 mm is larger than the D45 models, its IP67 protection and IK08 impact resistance qualify it for intensive outdoor spaces. Cutout: Ø 64 mm × H 80 mm. Lifespan: 30,000 hours.

Accessories: 24V DC driver not included, available as an accessory.

Key highlights:

  • 10° × 60° beam for a unique linear grazing effect on the ground
  • Honeycomb anti-glare diffuser
  • IP67 protection, IK08 impact resistance
  • 24 V DC power supply, low voltage
  • 3-year warranty
Ref: ZAM.E508

In-Ground Recessed Fixture ZAMBELIS D65 3W 24V 10x60° IP67 DESIGN Stainless Steel Without Driver

save_alt Download the technical sheet

Color

White warm - 3000K

Angle

Currently out of stock
Delivery: contact us
Pricing is only available to customers who are logged into their account and whose access request has been validated.
To request access, go here

In-Ground Recessed Fixture ZAMBELIS DESIGN Stainless Steel 24V: 10x60° beam for a linear grazing effect on outdoor surfaces

The in-ground recessed fixture ZAMBELIS DESIGN Stainless Steel E509 in stainless steel stands out with its specific 10° × 60° beam, a linear asymmetric profile that grazes floors, retaining walls or surfaces with a dramatic and sophisticated grazing effect. Powered at 24 V DC, it delivers 3 W for 218 lm in very warm light at 2,700 K, with a honeycomb diffuser to contain the light with precision.

Its diameter of Ø 65 mm is larger than the D45 models, its IP67 protection and IK08 impact resistance qualify it for intensive outdoor spaces. Cutout: Ø 64 mm × H 80 mm. Lifespan: 30,000 hours.

Accessories: 24V DC driver not included, available as an accessory.

Key highlights:

  • 10° × 60° beam for a unique linear grazing effect on the ground
  • Honeycomb anti-glare diffuser
  • IP67 protection, IK08 impact resistance
  • 24 V DC power supply, low voltage
  • 3-year warranty

General characteristics
Lifetime 30,000 h
Brand ZAMBELIS
Range DESIGN
Product family Ground lighting
Installation environment Exterior
Warranty 3 years
Electrical characteristics
Voltage 24 V DC
Power 3 W
Electrical class Class I
EU energy class 2019/2015 G
Lighting characteristics
Technology LED
Lumens output 218 - 230 lm
Lifetime LXBY L70B50
Diffuser Honeycomb
Beam Angle 60 ° x 10 °
IRC > 80
Physical characteristics and dimensions
Diameter 65 mm
Height 75 mm
Net weight 0.2 kg
Materials Stainless steel
Waterproof YES
IP IP67
IK IK08
Product color Gray
Cut-out ⌀64 x H80 mm
Working temperature -35 °C to 50 °C
Detailed color Stainless steel
Installation mode Recessed
Standards and regulations
Carbon footprint 32,9 kgCO2eq
