DomeLED Astral Emergency Detector CLAREO 18W DESIGN Black

DomeLED Astral CLAREO, design for residences in Emergency version

Its integrated battery provides 3h autonomy with a luminous flux of 270 lm when needed.

With its 18W power and its color temperature selector of 2700, 3000 and 4000K, this LED dome light will perfectly adapt to all your residential or other projects.

The product has a loopable terminal block, it also has a double cable entry to allow entry from the back or from the side. Available in standard version or with integrated detector, in black or white.

Ultra resistant: Anti-tearing, IP65 and IK10.
5-year warranty product for 50,000 operating hours.
Direct/Indirect diffusion for a designer halo lighting.

Box contents: 1 DomeLED Astral Emergency, 1 hex key, 4 hex screws, 4 screw covers, 3 mounting screws, 3 wall plugs, 3 sealing gaskets.

Key features:

3-hour battery autonomy
Classic version or with HF detection
Power and temperature selectors, loopable
IK10 anti-tearing polycarbonate housing

DomeLED Astral Emergency Detector CLAREO 18W DESIGN Black

Pricing is only available to customers who are logged into their account and whose access request has been validated.

To request access, go here

General characteristics

Lifetime	50 000 h
Brand	CLAREO
Range	DESIGN
Product family	Bulkhead lights

Installation environment	Residential, Commercial
Quick installation	YES
Repairable	YES
Warranty	5 years

Electrical characteristics

Voltage	200-240 V AC
Power	18 W
Electrical class	Class II
Facteur de puissance >	0,9
Taux de distorsion harmonique <	20 %

Power range	0-25 W
Sensor	YES
EU energy class 2019/2015	F
Detector type	High frequency
Maximum ground detection diameter	10 m

Lighting characteristics

Technology	LED
Lumens output	1400 - 1700 lm
Energy savings	- 10%
Lumens efficiency	90 lm/W
Lifetime LXBY	L70B10

Diffuser	Opale
Photobiological risk	GR0 - No risk
IRC >	80
UGR <	24
Lumens range	1100-1599 lm

Physical characteristics and dimensions

Diameter	275 mm
Height	67 mm
Materials	Polycarbonate
Waterproof	YES
IP	IP65
IK	IK10

Product color	Black
Diameter range	251-300 mm
Working temperature	-20 °C to 45 °C
Maximum installation height	6 m
Installation mode	Surface-mounted, Wall light
Type	SMD 2835

Standards and regulations

CEE	BAR-EQ-110

Standards	CE, RoHS
