DomeLED HF Detector CLAREO 18W Vandal-proof ADVANCE 2

PEP 15h18 (1).png

2000 lm anti-vandal bulkhead light with HF detection for residential use

This product features a double cable entry to allow electrical connection from below or from the side. Loop-through terminal block.

Series connection possible without exceeding 91 bulkhead lights.

Ultra resistant: Anti-tear, anti-vandal, anti-UV, IP65 and IK10.

Integrated adjustable HF motion detector with switch-off warning.

Box contents: 1 DomeLED HF ADVANCE 2 Detector with 1 anti-vandal screwdriver head, 2 connection terminals, 4 torx screws, 3 mounting screws, 3 plugs, 3 mounting seals, 2 cable ties and 4 screws for cable ties.

Notable features:

- Anti-tear housing

- Universal diameter: 300 mm

- IP65 / IK10

- Long lifespan

- Adjustable motion detector

DomeLED HF Detector CLAREO 18W Vandal-proof ADVANCE 2

Pricing is only available to customers who are logged into their account and whose access request has been validated.

To request access, go here

2000 lm anti-vandal bulkhead light with HF detection for residential use

This product features a double cable entry to allow electrical connection from below or from the side. Loop-through terminal block.

Series connection possible without exceeding 91 bulkhead lights.

Ultra resistant: Anti-tear, anti-vandal, anti-UV, IP65 and IK10.

Integrated adjustable HF motion detector with switch-off warning.

Notable features:

- Anti-tear housing

- Universal diameter: 300 mm

- IP65 / IK10

- Long lifespan

- Adjustable motion detector

General characteristics

Lifetime	90,000 h
Brand	CLAREO
Range	ADVANCE
Product family	Bulkhead lights

Installation environment	Residential, Commercial
Quick installation	YES
Repairable	YES
Warranty	5 years

Electrical characteristics

Voltage	220-240 V AC
Power	18 W
Electrical class	Class II
Facteur de puissance >	0,9
Taux de distorsion harmonique <	20 %

Power range	0-25 W
Sensor	YES
EU energy class 2019/2015	E
Detector type	High frequency, Motion
Maximum ground detection diameter	12 m

Lighting characteristics

Technology	LED
Lumens output	2000 lm
Energy savings	- 20 %
Lumens efficiency	110 lm/W
Lifetime LXBY	L80B10

Diffuser	Opale
Photobiological risk	GR0 - No risk
IRC >	80
UGR <	25
Lumens range	2000-2999 lm

Physical characteristics and dimensions

Diameter	300 mm
Height	85 mm
Net weight	0.7 kg
Materials	Polycarbonate
Waterproof	YES
IP	IP65
IK	IK10

Product color	White
Diameter range	251-300 mm
Working temperature	-20 °C to 40 °C
Detailed color	White
Maximum installation height	6 m
Installation mode	Surface-mounted, Wall light
Type	SMD 2835

Standards and regulations

CEE	BAR-EQ-110

Standards	CE, RoHS

Technical data sheets, IES files, installation instructions, certificates... are only downloadable for customers whose access has been validated. To request access, go here
