General characteristics
| Lifetime |
72,000 h |
| Brand |
CLAREO |
| Range |
ADVANCE |
| Product family |
Linear lights |
| Installation environment |
Traffic, Schools, Public space, Architectural, Decorative |
| Repairable |
YES |
| Warranty |
7 years |
Electrical characteristics
| Voltage |
220-240 V AC |
| Power |
7/11/15 W |
| Electrical class |
Class I |
| Dimmable |
Yes : depending on the reference |
| Facteur de puissance > |
0,95 |
| Taux de distorsion harmonique < |
15% |
| Power range |
0-25 W |
| EU energy class 2019/2015 |
C |
| Max power |
15 W Max |
Lighting characteristics
| Technology |
LED |
| Lumens output |
2250 lm |
| Energy savings |
- 40 % |
| Lumens efficiency |
150 lm/W |
| Lifetime LXBY |
L80B10 |
| Diffuser |
Prismatic |
| Beam Angle |
70 deg |
| Photobiological risk |
GR0 - No risk |
| IRC > |
80 |
| UGR < |
19 |
| Lumens range |
1100-1599 lm |
Physical characteristics and dimensions
| Height |
75 mm |
| Standard length |
55 cm |
| Width |
358 mm |
| Length |
558 mm |
| Net weight |
0.9 kg |
| Materials |
Aluminum |
| Waterproof |
No |
| IP |
IP20 |
| IK |
IK07 |
| Product color |
White |
| Working temperature |
-15 °C to 40 °C |
| Installation mode |
Surface mount with accessory, Pendant with accessory, Wall sconce, Wall sconce, Wall sconce |
| Type |
SMD2841 |
Standards and regulations
| CEE |
BAT-EQ-127, BAR-EQ-110 |
