New StripLED CLAREO ADVANCE 2

The LED strip that combines very high efficiency and flexibility.

This strip with a power of 3W/m and an efficiency of 150 lm/W is ideal for decorative use.

Sold in 5m rolls, this strip can be cut every 12.5cm to adapt to all projects.

The StripLED is supplied with 2 different wired connectors: input (x1) and linear connector (x3)

Dimmable: Yes, depending on driver

Key features:

  • Efficiency up to 150 lm/W
  • Sold in rolls of 5 m
  • Version IP20
  • 3M adhesive on the back
  • Wired connectors included (input x1 and linear x3)
  • Warranty 7 years

Warning: driver not included! The power supply, to be chosen in accessories, depends on the needs of your project and the total power of the strip.

Ref: FST.4896A2

StripLED CLAREO 3W/m IP20 ADVANCE 2

save_alt Download the technical sheet

Color

White warm - 3000K

Angle

In stock, next day delivery before 1pm
Pricing is only available to customers who are logged into their account and whose access request has been validated.
To request access, go here

General characteristics
Lifetime 100,000 h
Brand CLAREO
Range ADVANCE
Product family LED strips
Installation environment Architectural, Office, Reception, Hallway, Kitchen
Quick installation YES
Warranty 7 years
Electrical characteristics
Voltage 24 V DC
Power 3 W/m
Electrical class Class III
Power range 0-5 W/m
EU energy class 2019/2015 C
Lighting characteristics
Technology LED
Lumens output 208 - 467 lm/m
Lifetime LXBY L80B10
Beam Angle 120 deg
Photobiological risk GR0 - No risk
IRC > 90
SDCM < 3
Lumens range 250-499 lm/m
Physical characteristics and dimensions
Height 1.4 mm
Width 8 mm
Length 5,000 mm
Net weight 0.1 kg
Waterproof No
IP IP20
IK IK02
Working temperature -25 °C to 60 °C
Type SMD
Standards and regulations
Standards CE, RoHS
